1.15

SECTION 1 • SAFETY

290 Sundancer

D. WAKE / WASH

Power boat wakes can endanger people and vessels.

Each power boat operator is responsible for injury or

damage caused by the boat’s wake. Be especially

careful in confined areas such as channels or

marinas. Observe “no wake” warnings.

Reduce speed in congested waterway.

Be alert for No Wake markers.

! CAUTION

Freeboard – height of exposed hull from water line

to deck.

Ground tackle – general term referring to anchors,

anchor lines, etc.

Gunwale (pronounced gun’l) – meeting juncture of

hull and deck.

Hatch – an opening in deck to provide access

below.

Head – toilet or toilet area in a boat.

Headroom – vertical distance between the deck and

cabin or canopy top.

Helm – steering console.

Hull – the basic part of a boat that provides buoyancy

to ﬂoat the weight of the craft and its load.

Keel – the major longitudinal member of a hull; the

lowest external portion of a boat.

Knot – unit of speed in nautical miles per hour.

Lee – the side that is sheltered from the wind.

PFD – Personal Flotation Device; life preserver.

Port – term designating left side of the boat.

Rudder – movable ﬁxture at the stern used for

steering.

Scupper – hole permitting water to drain overboard

from deck or cockpit.

Sheer – curve or sweep of the deck as viewed from

the side.

Snub – to check or tighten a line suddenly.

Starboard – term designating right side of the boat

Stern – the aft end of a boat.

Stern drive – outboard unit of an inboard/outboard

(I/O) engine installation.

Stringer – longitudinal members fastened inside the

hull for additional structural strength.

Transom – transverse part of stern.

Wake – disturbed water that a boat leaves behind

as a result of forward motion.

Windward – toward the direction from which the

wind is blowing.

20. NAUTICAL TERMS

Abeam – object 90 degrees to center line on either

side of boat.

Abaft – a point on a boat that is aft of another.

Aft – toward the rear or stern of the boat.

Beam – the width of a boat.

Bow – the fore part of a boat.

Bow Eye – bolt with looped head mounted on

extreme forward part of bow.

Bulkhead – vertical partition in a boat.

Chine – meeting juncture of side and bottom of

boat.

Chock – deck ﬁtting, used as guides for mooring

or anchor lines. Also, a wedge to stop wheels from

rolling.

Cleat – deck ﬁtting with arms or horns on which lines

may be made fast.

Cockpit – an open space from which a boat is

operated.

Deck – upper structure which covers the hull between

gunwales.

Draft – depth of water required to ﬂoat boat and its

propulsion system.

Fathom – six feet.

Fenders – rope or plastic pieces hung over the side

to protect the hull from chaﬁng.
