7.8

SECTION 7 • OPTIONS & ACCESSORIES

290 Sundancer

8. AUTOMATIC FIRE EXTINGUISHER

SYSTEM

Your boat is equipped with an

automatic fire extinguisher

system located aft of the

engine. In the event of

a fire, the heat sensitive

automatic head will release

the extinguishant as a vapor,

totally ﬂ ooding the area in ﬁ re-

killing concentrations.

IF ACTUATION OCCURS,

IMMEDIATELY SHUT

DOWN ALL ENGINES,

POWERED VENTILATION,

ELECTRICAL SYSTEMS

AND EXTINGUISH ALL SMOKING MATERIALS.

DO NOT IMMEDIATELY OPEN THE ENGINE

COMPARTMENT!! THIS FEEDS OXYGEN TO

THE FIRE AND FLASHBACK COULD OCCUR.

Allow the exinguishant to “soak” the compartment

for at least ﬁ fteen (15) minutes and for hot metals or

fuels to cool before cautiously inspecting for cause

of ﬁ re. Have portable extinguishers at hand and

ready. Do not breathe fumes or vapors caused by

the ﬁ re.

Note: Do not over ﬁ ll the holding tank as this will

ﬂ ood the vent ﬁ lter and render it useless. Filter

replacement will then be required. See Parts

Manual for correct replacement ﬁ lter.

7. MACERATOR DISCHARGE PUMP

WITH SEACOCK INTERLOCK SYSTEM

(OPTIONAL)

If equipped, the optional macerator (See Figure

7.7.3) gives the boat operator the means of

discharging the holding tank contents directly

overboard through a seacock in the bottom of

the hull. This is available in conjunction with the

dockside pump out.

Since direct overboard discharge is prohibited in

many areas, the macerator seacock is normally

closed. The macerator seacock is equipped with a

system interlock switch which prevents the operation

of the macerator when the macerator seacock is

closed. The light on the DISCHARGE PUMP switch

on the DC Distribution Panel will be lighted when the

macerator is operational. If the light is not lighted,

it is visual conﬁ rmation the macerator seacock is

closed and that the macerator cannot be operated.

Check that the macerator seacock handle is in the

open position and the light on the switch is lighted

before operating the macerator.

TO OPERATE THE MACERATOR:

1. Turn ON the DISCHARGE PUMP breaker on

the salon DC distribution panel and open the

waste discharge seacock located on the bilge

ﬂ oor (See Fig. 4.8.1 for seacock location).

2. Operate DISCHARGE switch at the WASTE

SYSTEM CONTROL area on the main

distribution panel.

3. When tank is empty, turn the switch to OFF and

close waste discharge seacock.

NOTE: Turn OFF discharge pump to prevent

accidental discharge.

MAINTENANCE

Prior to each use and at regularly scheduled

intervals, cycle the macerator seacock handle

open and shut to ensure proper operation of the

seacock

This boat may be equipped with an optional overboard

discharge valve.

Discharging of sewage directly overboard is for use

where approved only.

NOTICE

There is the possibility of being ﬁ ned for having an

operable overboard discharge in U.S. waters. Removing

handle of seacock while in closed position, or other

means must be utilized to avoid ﬁ ne.

NOTICE

AUTOMATIC FIRE

EXTINGUISHER

( FIG. 7.8.1)
